We created an outdoor sunroom that is both functional and aesthetically pleasing for a private courtyard home in Florida, USA. The area is affected by hurricanes all year round, with rainy summers and plenty of light. The client wanted a light, hurricane-proof, rain-proof retreat that could accommodate family gatherings and outdoor lounging without taking up too much space on the patio. Location and Environmental Challenges： The project is located on the east side of the residential courtyard, adjacent to the main building, on a level lawn site that requires integration into the courtyard landscape and wind-resistant structural stability. With an average of 3.2 hurricanes per year in Peninsula Florida and frequent short-term rainfall in the summer, the core of the design needed to address: Structural wind pressure during hurricane season (target wind rating ≥180km/h); Waterproofing and sealing during heavy rains;…
Project Address: Dubai Client's Requirement: The indoor roof of a swimming pool in the backyard of a villa meant building a mobile sunroom on the client's steel structure. The price of glass was too high, so the client chose polycarbonate panels with uv coating. T6 profile was required. Site condition: Site condition:The local climate is above 40 degrees, very hot, little wind and dusty. The project is in the backyard of the villa, the product size 9208*6145mm,extension track 2340mm on each side, the track are installed on the steel structure. Workers installed for the first time, communication language barriers, but due to modular installation, the degree of installation is simple. Design solution: The customer requires electric power and the opening method is from the center to both sides. At the same time, it is required to open completely in the…
In a high-end villa area in Qatar, Sunray has successfully created a breakthrough intelligent sunroom project. The project is located in the tropical desert climate zone at 25°16'N latitude, facing severe environmental challenges such as extreme heat, strong UV rays and frequent sand and dust. customer expectation： The client wanted to create a modern sunroom that could withstand temperatures up to 50°C, block strong ultraviolet rays, and have intelligent dimming functions, while maintaining architectural aesthetic unity and low maintenance costs. The “Four Dimensions of Integration” innovative design program： 1) The material is made of triple composite glass (6mm+1.52PVB+6mm Low-E) and aviation grade 6063-T5 aluminum alloy frame; (2) Intelligent system equipped with electrochromic dimming 3) The protection system adopts high-density dustproof screen mesh and intelligent motorized sunshade 4) Aesthetic treatment with hidden nodes and customized surface treatment Project results： It maintains…
On the third floor rooftop terrace of a commercial area in Saudi Arabia (height of 21 meters), we successfully created an electric sunroom restaurant with both aesthetics and functionality. Facing the extreme heat of more than 40℃, strong wind and sandy environment, and the challenge of constructing at a height of 21 meters, we customized the perfect solution for the owner. Client need: Build a budget-friendly sunroom dining room that requires 80%+ insulation efficiency, features a curved corner design for dual-mode power/manual opening and closing, and integrates safety rails and easy daily maintenance. For the installation space of 32m×8m×8m and the limited construction conditions, our design program has fully considered every detail. Design proposal: 1. The project adopts innovative three-section modular structure, and the main body is made of 80×160×6mm high-strength aluminum alloy frame with 15mm thickened articulated steel plate…
